Input:1*HDMI,1*3.5mm Audio IP Output:HTTP/RTSP/RTMPS/SRT/UDP/RTP/ONVIF/HLS Battery:Built-in Battery,Can use about 3 hours Video Encoding:H.265/Hevc,H.264/Mpeg4 Audio Encoding:MP3, AAC, G.711 Resolution:Max 1080P@60fps Warranty:5 Years Warranty

GET A QUOTE

Description

Product Description
1-channel HD HDMI input, 1-channel audio input.
Dual streams output.H.264 format, Audio: MP3, AAC, G.711 format.
Configuration could be freely adjusted according to the need.
Support SRT/HTTP / RTSP / RTP/ TCP / RTMP / FLV/ UDP / ONVIF / HLS protocols.
Red indicator: power. Yellow: Streaming status. Green: Network

• Support 2G/3G/4G/WIFI/cable network optional
•The shoe base is fixed to the camera
• Support 1920x1080p/1920x1080i/1280x720p/720*576i/720*576p/640*480i solutions (customized)
• Support HDMI input，H.265 latest architecture
• support more units in one computer to work.
• Supports WINDOWS and LINUX etc
•Support multiple devices display on a computer at the same time
•Support SRT/RTSP/RTP/RTMP/HTTP/UDP/ONVIF/HLS unicast and multicast protocol (RTMP support adding users and changing passwords)
• Support Main TS stream and the sub TS stream use in different network protocols for transmission ,H264/H265
• Encoding level: 1, 2, 3, 4 and 5 (the higher the level ,the larger of the code flow fluctuation ratio )
•Coding Standards BASELINE PROFILE / MAIN PROFILE / HIGH PROFILE, H.265:audio MP3, AAC, sampling rate: 32000,44100, etc., encoded audio bit rate: 48K, 64K, 96K, 128K, 160K, 192K, 256K
• Video packaging: A mode: FFMPEG, B mode: VLC
•Compatible with Wowza/FMS/RED5 streaming media server etc, work in with streaming media server to push the streaming , to achieve a live streaming
• Rate Control CBR / VBR 16KBIT / S ~ 12MBIT / S
•Video packaging: A mode: FFMPEG, B mode: VLC
•Transmission: TCP, UDP, 1000M (RJ45 Duplex network port)
•Support WEB access in Chinese/English, passwords changing, WAN remote management (WEB)
•Support OSD in Chinese/ English, support OSD rolling, images superimposing, support adding LOGO ,Characters and symbols;
Adjustable coordinates: 1920x1080; The font size resolution: 8 to 72.
•Support DHCP gaining IP automatic ,support One-key recovery, upgrade and remote maintenance
•Image settings: contrast ratio, brightness, tones, saturation, noise detection, sharpness, filtering
•Support build-in or external methods , support left and right sound channel , Support audio gain ,be able to turn volume individually
•Support coding without video signal;
•Complete the setting effect immediately, don’t need to restart
•Support one-key recovery of the default configuration
• support STB decoding
•The low power consumption design
• Battery power supply,can use 5-6 hours

Specification

Model	2/3/4G++WIFI +Lithium battery HDMI encoder
Output	1Channel HDMI input, 1 Channel line in audio
Video	1 channel IP signal output
Audio	Input resolution	Up to 1920x1080p 60FPS, standard HDMI resolution
	Coding standard	H.265 / H.264
	Coding level	H.265 main profile H.264 BASELINE PROFILE H.264 MAIN PROFILE H.264 HIGH PROFILE
	Encoded size	640360~19201080
	Video bit rate	CBR/VBR: 16KBIT/S~12MBIT/S
	Video frame rate	5- 60 fps
	OSD	Text, Image
IP Output	Input selection	1 channel embedded audio hdmi, 1 channel 3.5MM independent audio support audio gain
	Audio coding	AAC/MP3/G.711
	Audio bit rate	64Kb/s~384Kb/s
	Sampling rate	32000、44100、48000 etc
System	1 RJ 100M / 1000M adaptive Ethernet port, dual-stream( H.265/264 TS stream)
