Modulation |
Standard | ARIB STD-B31 |
| Bandwidth | 6M | |
| Constellation | QPSK, 16QAM, 64QAM | |
| Guard Interval | 1/32, 1/ 16, 1/8, 1/4 | |
| Transmission Mode | 2K, 4K, 8K | |
| Code rate | 1/2, 2/3, 3/4, 5/6, 7/8 | |
| MER | ≥40db | |
| RF frequency | 50~900MHz, 1KHz step | |
| RF output level | -20dBm~+10dBm(87~ 117dbµV), 0.1dB stepping | |
| RF Output | 24 non-adjacent carriers output | |
Multiplex |
Max PIDs | 256 per channel |
| Functions | PID remapping (auto/manually optional) | |
| PCR accurate adjusting | ||
| PSI/SI table automatically generating | ||
IP Input |
3* 128 IP(SPTS/MPTS) input over UDP and RTP, RJ45, 1000M/ 100M, Unicast/Multicast | |
ASI input |
6 ASI input, DVB standard, BNC connector | |
System |
LCD/Keyboard operating and web-based NMS support | |
| Ethernet software upgrading | ||
General |
Dimension(W*D*H) | 482mm×340mm×45mm |
| Temperature | 0~45℃(work)；-20~80℃(storage) | |
Power supply |
AC 110V±10% ，50/60Hz AC 220V±10% ，50/60Hz |
|
